18.2 m / 59’ 8”
17.6 m / 57’ 8”
7.3 m / 23’11”
0.6 m / 1’11”
22.1 ton / 48,620 lbs
606 L / 160 Gal
1,514 L / 400 Gal
460 L / 122 Gal
606 L / 160 Gal
1,514 L / 400 Gal
460 L / 122 Gal
260 L / 69 Gal
1. The hull construction utilizes marine grade corrosion-resistant 5083-H116 aluminum alloy, the deck & upper structure are built with 5052-H32 aluminum alloy.
2. Shipyard is equipped with Laser cutting plate & digital bending machineries, and experienced skill welders to assure precision & quality construction.
3. The welding process is performed in accordance to the Chinese classification society's "Steel Ship Classification Code" and "Material and Welding Code".
4. Exterior paint: UV resist PU paint for yachts.
5. Anti-fouling bottom paint: Apply 3 layers of primer coats and 2 layers of top coats.
1. Fiberglass composite hardtop are formed in one piece using “Vacuum Infusion” technique.
- Entire exterior surface is infused with anti-osmotic vinyl ester resin.
- Cored with high density marine foam and laminated with layers of engineered e-glass fabrics.
2. Gel Coat: ASHLAND® yacht gel coat.
3. Exterior deck surface:
Standard: Molded diamond pattern non-skid deck surface.
Optional: Optional PVC synthetic teak decks
1. All exterior guard rails and stanchions are made with 5052 aluminum alloy tubes， 38mm in diameter, & are secured by aluminum backing plate; Height of the stanchions: are 32” (81cm).
2. Aluminum anchor roller & guide rail.
3. Cleats: (9) Nine 316 stainless steel cleats.
4. Pulpits with flagpole holder
5. Swimming ladder.
1. All external windows, above deck will be frameless, directly bonded to the surface;
- front windshields are 10mm insulated, tempered glass;
- side windows are 8mm tinted tempered glass.
2. Foredeck watertight door: One (1) flush-mounted door w/ upper glass.
3. Portholes: Eight (8) units, each is fitted with insect screen.
4. Watertight engine room door: Two (2) aluminum, noise insulation doors.
5. Salon aft. door to cockpit: One (1) white powder coated aluminum door
6. Salon starboard side door: One (1) white powder coated aluminum door
1. Full length transom seat in the cockpit.
2. Outdoor bar on port with synthetic granite countertop, one (1) foldable faucet, bar sink & waste bin locker.
3. Stairway with courtesy lights from cockpit to flybridge.
4. Hot/cold deck shower at swim platform.
5. Transom shore AC electric power connection.
1. Reinforced windlass mount.
2. Anchor: 40 kg, polished stainless-steel anchor.
3. Chains: (5/16 HT rated, 200 ft.) are placed in the chains lockers. The chains are fixed to the deck beams by means of a quick-release hook, near the hatch openings.
4. Fresh water wash down outlet in the chain locker.
5. Overboard drain inside chain locker.
6. Windlass: Electric reversible anchor windlasses with 2 station controls.
1. Access from the cockpit by a staircase with teak steps.
2. Integrated aft sunbed.
3. Outdoor bar on port with synthetic granite countertop, one (1) foldable faucet, bar sink & waste bin locker.
4. Flybridge helm station with：One (1) steering wheel，engine instrument panel & control switches for designated equipment, one (1) compass, one (1) Helm seat, & two (2) cup holders.
1. Standard equipment：Twin 600 hp WEICHAI® WP13Y600-21E220 marine diesel engines equipped with HANGCHI® gear boxes, & electronic engine control.
2. Optional equipment：Twin 550 hp CUMMINS® QSB6.7 marine diesel engines equipped with ZF® gear boxes & electronic engine control.
1. AC Generator: 13kw / 50Hz generator with sound shield and air/water separation muffler.
2. AC system: 230 V AC system.
3. Air Conditioning: 230 Volt AC / 50HZ reverse cycle with total 70,000 BTU capacity; including air conditioning vents to all heads.
4. AC sockets and switches with trim plates.
5. Batteries (placed in enclosed fiberglass battery boxes):
- 4 heavy-duty marine (12V/200AH) AGM batteries for 12VDC house system.
- 4 heavy-duty marine (12V/200AH) AGM batteries for engines starting
- 1 heavy-duty marine (12V/120AH) AGM batteries for generator starting.
6. Battery charger: one (1) 30-amp 12V battery charger, and one (1) 40-amp 24V battery charger.
7. Battery switches.
8. Complete backlit AC/DC distribution panels with magnetic circuit breakers & digital volt & amp meters.
9. Complete electrolysis bonding system.
10. DC electric system: 24V DC system.
11. 24V DC electric horn.
12. GFI outlets for all wet locations.
13. LED lights.
14. CE or CCS certified marine grade wirings.
15. Navigation lights: AQUA SIGNAL® or Sea Star® lights.
16. Searchlights: GOLIGHT®.
17. Shore power connections: One (1) 50-amp outlet at starboard stern corner.
1. Bilge pumps with high water level alarm:
- RULE® DC electrical bilge pumps (six 1500gph units)
- Emergency manual bilge pump (two units).
2. Electrical outlets: One GFI power (AC) socket.
3. Engine mounts: Vibration damping mounts for engines.
4. Engine room AC and DC lights with switches next to access door.
5. Engine room bulkheads are watertight and insulated with extra foam sound insulation.
6. Engine room floor board: Removable non-skid floor panels。
7. Engine room ventilation system with exhaust blowers.
8. Engine room wall are finished with white color, perforated aluminum panels.
9. Engines, filters & all metal parts are electrically bonded.
10. Fire extinguishing system w/ automatic shut-off system.
11. Fuel Filters: RACOR® fuel filters for engines and genset.
12. Saltwater water pump: one (1) for wash down & emergency use.
13. Fresh water pumps: one (1) 24V DC.
14. Shore water inlet connection.
15. Water heater: One 80-liter electric water heater.
